Industrial labelling systems explained

What a labelling system has to get right

A label is only useful if it lands in the same place every time, stays readable, and carries the data the next reader expects. That means three things working together: handling that presents the product squarely, an applicator that places the label without dragging or bubbling it, and print data that matches what the scanner downstream is looking for. Arca builds these as linear handling systems, so movement is driven rather than mechanically derived, which cuts wear and noise and keeps placement repeatable at line speed.

The Light and Solid series

Light is the compact series, with steel bases, stainless versions available, servo motors, one-side adjustments and millimetre scales for setting position by hand. Solid is the robust, expandable series, and it allows labellers on both operating sides, which is what you need when a product has to be labelled front and back or top and side in one pass. Solid covers the Combi, Skytech and Hightech configurations, and Hightech non-stop systems run at more than 350 pieces per minute.

Application positions

Wrap around up applies vertically with the labeller opposite the operator side; wrap around down handles horizontal cylindrical products on idle roller conveyors. Side, top and two-sides cover the flat panel cases, and Combi applies to multiple sides without replacing components. For lower volumes, the semi-automatic wrap around machines take manual loading and convert between seal, top, base and wrap around modes.

Format changes without change parts

Format change is where most labelling lines lose their day. Recipes hold the settings, so a change of SKU is a selection rather than a strip-down. The digital interface is a 4.3 inch colour touchscreen holding 200 product programs, each named up to 15 characters. Worktop height adjusts by 200 mm using the Arca Clip system, so the machine can be set to the conveyor rather than the conveyor to the machine.

Print, code and mark

Thermal transfer, thermal inkjet and fibre laser marking are all available, so the same handling platform can print a variable label, code directly onto the pack, or mark without consumables. Where the job is applying a pre-printed or on-demand label to a case, print and apply labellers cover that specifically.

Verification and traceability

The Graphic MMI 4.0 interface is a 10 inch industrial PC panel with an SSD, encrypted audit trail, biometric access control and SQL data export over USB or Ethernet, and it is built to comply with 21 CFR Part 11. Inline barcode scanning and verification checks that a label is present and grades it, so a failed label triggers a re-apply or a reject rather than reaching the customer.

Pharma, hygiene and harsh areas

Pharma Seal 4.0 is the tamper-evident case sealing machine, built in AISI 304 stainless in a compact balcony design with indexed toothed belt transport so cases cannot slip in the drive. Elsewhere the choice is a shot blasted steel finish or epoxy powder coated iron, with an IP54 electrical cabinet on the Light series and IP68 shielded cables. Rotating disks and spindles are built without dangerous openings and gaps are held under 4 mm, and the machines meet the EMC and Low Voltage directives.

Specification

Series: Light for compact lines; Solid for robust, expandable builds with labellers on both operating sides
Application positions: Wrap around up and down, side, top, two sides, and Combi for multiple sides without changing components
Throughput: Hightech non-stop systems run at more than 350 pieces per minute
Control: 4.3 in colour touchscreen holding 200 product programs, or a 10 in industrial PC panel with SSD
Motors: Brushless, constant torque at any speed, no oil leakage and no routine maintenance

Marking: Thermal transfer, thermal inkjet and fibre laser markers; digital thermal transfer coders with touchscreen control
Construction: AISI 304 stainless steel, shot blasted steel finish or epoxy powder coated iron
Protection: IP54 electrical cabinet on the Light series; IP68 shielded cables and metal cable blocks
Compliance: EMC 2014/30/CE and Low Voltage 2014/35/CE; 21 CFR Part 11 audit trail on the Graphic MMI 4.0
Specialist systems: Pharma Seal 4.0 tamper-evident case sealing and Striped Linerless 5000 for linerless media

FAQs about Industrial Labelling Systems

Quick answers on media, speeds, placements, verification, integration and upkeep.

What media can these systems run?

Pressure-sensitive labels (paper/synthetic) and, on supported models, linerless media for reduced waste and longer runs.

How fast can they apply labels?

Application speed depends on label size and placement; systems are specified to match your line speed and print density.

Which placements are supported?

Top, side, wrap, corner-wrap, dual-panel (A/B) and pallet SSCC—configured per SKU and compliance needs.

Do I need mechanical change parts between SKUs?

No—Arca’s linear handling enables change-part-free adjustments via recipes for most formats.

Can we verify barcodes inline?

Yes—add scanners/vision to check presence and grade; failed labels can trigger re-apply or reject.

How do these systems integrate with printers and databases?

Via PLC and data links to WMS/MES/ERP; print data (e.g., GS1) feeds the printer, and results return for traceability.

Are they suitable for washdown or harsh areas?

Stainless and IP-rated options are available for hygienic or dusty environments.

What maintenance is required?

Routine cleaning of pads/rollers, checks on sensors and drives; service intervals are long thanks to maintenance-light design.

Can we run different label materials/adhesives?

Yes—paper or synthetics with permanent, removable or freezer-grade adhesives; we validate to your substrate and temperature.

Do they support pallet labelling?

Absolutely—dual-side pallet (A/B) with height compensation, SSCC printing and verification for despatch compliance.
